| Decoder parameters | |||
| Working current:3.5 V ± 10%x100mA | Light source:617LED | ||
| Sensor: CMOS | lumination: 6500K LEDs | ||
| CPU:ARM 32-bit Cortex | Decoding speed: 500/sec | ||
| Depth of Filed:30-600mm | Indication:Buzzer & LED | ||
| Decoding accuracy:≥ 5mil | |||
| Trigger Mode:Button, Continuous, Auto-Induction | |||
| Printing Contract :≥30% | |||
| Scanning angle: Angle of rotationt± 30°, inclination± 60°,declination± 60° | |||
| Anti-interference: 0-100000Lux Max | |||
| Decode Capability: 1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Standard 2 of 5(IATA), Coda bar(NW-7), MSI Plessey, ISBM, ISSN, China post etc. 2D: QR Code, Data Matrix, PDF417, etc. |
|||
| Button life: 10000,000 times | LED life: 100000 hours | ||
| Drop test: 1.8m | transmission: Bluetooth & USB-Wire | ||
| Working temperature: -20°C to 50°C | Relative humidity: 5%-95% | ||
| Wireless Parameters | |||
| Wireless type: Bluetooth | Transmission distance: 50m | ||
| Battery: 3.7V-1200mAh | Charging power: 5V-400mA | ||
| Working mode: lnstant upload mode,Storage mode, Not lost mode | |||
| Storage: 4MB≈40000 EAN13 barcodes | |||
| Working time: Full load≈15hours,Normal use ≈3 to 8days | |||
Features and Benefits
- Two setting ways: Menu button or Settings barcode.
- Bluetooth-HID+BLE+2.4G+Wired.
- Three Modes(Bluetooth/2.4G/Wired) can be switched freely.
- Quick connection, Fast secondary connection.
- 16MB storage.
- Support Instant upload Mode、storage Mode.
- Full ASCII character editing.
- Support 25 Language.
- Efficient power management, long working hours.
- Buttons: long life, comfortable, quiet.
What’s in the box?
- EV-DM3-Black Barcode Scanner*1
- USB Cable*1
- Wireless Receiver*1
- Safety Rope*1
- Scanner User Manual*1
